Atosa Stainless Steel Undercounter Refrigerator 36" - 2 Doors - AUR36SD

The Atosa AUR36SD is a two-section, two-door reach-in undercounter refrigerator for restaurants, bars, cafes and prep lines that need cold storage under a work surface. It measures 36-3/8" wide, 30" deep and 32-1/2" high and holds 8.6 cu. ft. at 35°F to 38°F. A rear-mounted, self-contained 1/6 HP system runs on R290 refrigerant and plugs into a standard 115V outlet with a NEMA 5-15P plug, drawing 2.3 A. The cabinet is stainless steel inside and out with a galvanized steel back, and it rolls on pre-installed 2" casters. East Bay Restaurant Supply ships this model with free shipping.

Key features

• 8.6 cu. ft. of refrigerated storage split across two sections, each with its own solid hinged door
• Electronic temperature controller holds 35°F to 38°F
• Field reversible doors for left-hand or right-hand swing
• Self-closing doors with a stay-open feature, plus magnetic gaskets that seal the door closed
• Rear-mounted, self-contained refrigeration with R290 hydrocarbon refrigerant and automatic condensate evaporation
• 1/6 HP compressor on 115V / 60 Hz / 1-phase, 2.3 A, NEMA 5-15P plug
• Stainless steel exterior and interior with a galvanized steel back
• Epoxy-coated adjustable shelves, one pre-installed per section, made to resist moisture, rust and corrosion
• Pre-installed 2" heavy-duty swivel plate casters, including casters with brakes
• cETLus listed to UL 471 and CSA C22.2 No. 120, and ETL Sanitation listed
• 3-year parts and labor warranty and 5-year compressor warranty

Atosa AUR36SD specifications

Brand	Atosa (Atosa USA, Inc.)
Model number	AUR36SD
Product type	Undercounter refrigerator, reach-in
Sections / doors	2 sections, 2 solid hinged doors
Door features	Self-closing with stay-open feature, field reversible, magnetic gaskets
Capacity	8.6 cu. ft.
Exterior width	36-3/8"
Exterior depth	30"
Exterior height	32-1/2"
Temperature range	35°F to 38°F
Temperature control	Electronic digital controller
Refrigeration system	Self-contained, rear-mounted, automatic evaporation
Refrigerant	R290 (hydrocarbon)
Compressor	1/6 HP
Electrical	115V / 60 Hz / 1-phase, 2.3 A
Plug	NEMA 5-15P (15 A, 125V)
Shelves	2 epoxy-coated adjustable shelves, 1 per section
Exterior material	Stainless steel, galvanized steel back
Interior material	Stainless steel
Casters	2" heavy-duty swivel plate casters, pre-installed, including braking casters
Net weight	161 lb
Shipping weight	198 lb
Certifications	cETLus (UL 471, CSA C22.2 No. 120), ETL Sanitation
Warranty	3 years parts and labor; 5 years on the sealed compressor

Frequently asked questions

What outlet does the Atosa AUR36SD need?

It needs a standard grounded 115V, 15 A receptacle (NEMA 5-15R), because it ships with a cord and NEMA 5-15P plug. It runs on 60 Hz single-phase power and draws 2.3 A.

Is the AUR36SD a refrigerator or a freezer, and what temperature does it hold?

It is a refrigerator. The electronic controller holds 35°F to 38°F, so it is not suitable for frozen storage.

Will the AUR36SD fit through a standard doorway?

Yes, if you move it through depth-first: it is 30" deep, which clears a 36" doorway. At 32-1/2" high it is well under an 80" door opening. The 36-3/8" width is wider than a 36" doorway, so it will not go through facing forward.

How many shelves come with it, and can I get drawers instead?

It comes with two epoxy-coated adjustable shelves, one in each section. Atosa offers drawer cartridges as an optional accessory that can be installed in the field.

What certifications does the AUR36SD have?

It is cETLus listed and ETL Sanitation listed. cETLus means Intertek has tested it to the North American electrical safety standards for commercial refrigerators (UL 471 and CSA C22.2 No. 120). ETL Sanitation means it meets the food equipment sanitation standards that health inspectors look for in commercial kitchens.

What warranty comes with the AUR36SD?

Atosa covers the cabinet and all parts against defects in materials and workmanship for 3 years, parts and labor. The sealed compressor gets 2 more years of coverage, for 5 years from the date of original installation. The extra compressor coverage applies only to the sealed compressor parts. It does not cover the cabinet, paint, temperature control, refrigerant, metering device, motor starting equipment or fan assembly. Claims go directly to Atosa and must include the model number, serial number, proof of purchase and installation date. Atosa offers extended coverage of up to 5 years.

What factory options are available?

Atosa offers field-installable drawer cartridges, 1.2" and 1.5" low-profile swivel plate casters, 4" and 5" swivel stem casters, and extended warranty coverage of up to 5 years.

How does the AUR36SD compare with other models in the Atosa AUR line?

The AUR36SD is the 36" two-door model, with 8.6 cu. ft. and a 1/6 HP compressor. The AUR27SD is a 27-1/2" one-door model with 6.4 cu. ft. The AUR48SD is a 48-1/4" two-door model with 11.8 cu. ft. All three are 30" deep and 32-1/2" high. If you need a 36" freezer, look at the AUF36SD.

Does it ship free, and how is it delivered?

Yes, this model ships free. It ships on a pallet by freight truck. A lift gate fee applies to large items like this one if you don't have a loading dock and is calculated at checkout.
