Atosa Heated Display Case Stainless Steel Countertop 7.1 Cu Ft CHDS-71

The Atosa CHDS-71 is a 7.1 cu. ft. countertop heated display case with straight front glass. It is built for delis, convenience stores, concession stands, cafeterias and bakeries that hold and sell hot food at the counter. The case measures 35-7/8" wide, 22-1/2" deep and 26-1/2" high, and an electronic digital controller holds it between 86°F and 194°F. Three stainless steel shelves, a removable water pan for humidity and LED interior lighting come standard, and staff load from the back through two sliding glass doors. It runs on 115V single-phase power at 1650 watts and 13.7 amps through a NEMA 5-20P plug. East Bay Restaurant Supply ships this model with free shipping.

Key features

• Straight (square) front glass gives customers a full view of the product.
• Two rear sliding glass doors let staff load and serve from behind the counter.
• Magnetic door gaskets seal the doors without latches. The gaskets are NSF approved.
• Electronic digital controller with an adjustable range of 86°F to 194°F.
• Removable water pan adds humidity so held food dries out more slowly.
• Three stainless steel shelves come standard.
• LED interior lighting.
• Stainless steel inside and out.
• 1.5" leveling legs for setting the case level on the counter.
• 1650 W at 115V, 13.7 A, with a NEMA 5-20P plug.
• cETLus listed for electrical safety and ETL Sanitation listed.

Atosa CHDS-71 specifications

Brand	Atosa
Model number	CHDS-71
Product type	Countertop heated display case
Front glass style	Straight (square) front glass
Doors	2 rear sliding glass doors
Capacity	7.1 cu. ft.
Exterior width	35-7/8"
Exterior depth	22-1/2"
Exterior height	26-1/2"
Temperature range	86°F to 194°F
Controller	Electronic digital
Shelves	3, stainless steel
Humidity	Removable water pan
Lighting	LED interior
Electrical	115 V / 60 Hz / 1-phase, 13.7 A
Power	1650 W
Plug	NEMA 5-20P
Exterior material	Stainless steel and glass
Interior material	Stainless steel
Door gaskets	Magnetic, NSF approved
Legs	1.5" leveling legs
Net weight	121 lb
Shipping weight	168 lb
Certifications	cETLus, ETL Sanitation
Warranty	1 year parts and labor

Frequently asked questions

What outlet does the Atosa CHDS-71 need?

It needs a NEMA 5-20R receptacle on a 115V, 20-amp circuit. The cord ends in a NEMA 5-20P plug, which will not fit a standard 15-amp 5-15R outlet. The unit draws 13.7 amps at 1650 watts, so check that the circuit is not shared with other heavy loads.

What temperature does it hold? Is it a refrigerator?

It is a heated case, not a refrigerator. The digital controller adjusts from 86°F to 194°F. That range includes the 135°F minimum hot-holding temperature in the FDA Food Code.

Will it fit on my counter and through my doorway?

Yes. The case takes up 35-7/8" of width and 22-1/2" of depth on the counter and stands 26-1/2" high. At 22-1/2" deep it passes easily through a standard 36" doorway. It weighs 121 lb, so plan on two people to lift it onto the counter.

How much does it hold?

It has 7.1 cu. ft. of heated space on three stainless steel shelves. That suits wrapped sandwiches, pastries, empanadas, fried chicken, pizza slices and other grab-and-go items.

How do I keep food from drying out?

Fill the removable water pan. It adds humidity inside the case, and the magnetic gaskets on the sliding doors help keep that moisture and heat in.

What certifications does it have?

It is cETLus listed and ETL Sanitation listed. cETLus means Intertek has tested it to North American electrical safety standards for the US and Canada. ETL Sanitation shows it meets the sanitation standards health inspectors expect for commercial food equipment.

What warranty comes with it?

Atosa covers it for 1 year parts and labor, counted from the date the unit ships from Atosa. Labor covers standard straight-time rates and reasonable travel time. The warranty excludes damage from alteration, neglect, abuse, misuse, accidents, shipping or installation, fire, flood and acts of God. It does not apply outside the continental United States. Claims go directly to Atosa and must include the model number, serial number, proof of purchase and installation date.

How does the CHDS-71 differ from the CHDS-53, CHDC-56 and CHDC-44?

The CHDS-71 is the largest case in this Atosa countertop heated line. The CHDS-53 has the same straight glass but is narrower: 5.3 cu. ft., 1250 W, 10.5 A, with a NEMA 5-15 plug. The CHDC-56 is about the same width with curved front glass, 5.6 cu. ft., and the same 1650 W and NEMA 5-20 plug. The CHDC-44 is the smallest curved-glass model at 4.4 cu. ft., with a NEMA 5-15 plug.

Does it ship free, and how is it delivered?

Yes, this model ships free. It ships on a pallet by freight truck. A lift gate fee applies to large items like this one if you don't have a loading dock and is calculated at checkout.
