Atosa Insulated Stainless Steel Warming Cabinet - 24 Pan - ATWC-24

The Atosa ATWC-24 is a full-height, mobile, insulated warming and holding cabinet for restaurants, caterers, cafeterias and institutional kitchens that need to hold large batches of cooked food at serving temperature. It holds twenty-four 18" x 26" pans on integrated slides in a 21-1/2" wide by 31-3/4" deep by 69-3/4" high footprint. Temperature adjusts from 90°F to 205°F, and an LED display shows cabinet temperature. It runs on 120 V, 60 Hz, single-phase power at 13.2 A and 1,580 W, and the interior and exterior are stainless steel. East Bay Restaurant Supply ships this model with free shipping.

Key features

• Holds twenty-four 18" x 26" full-size sheet pans on integrated slides
• Adjustable heating mode from 90°F to 205°F, set by dial, with an easy-to-read LED display
• Stainless steel exterior and interior
• Fully insulated cabinet with environmentally friendly foaming material to limit heat loss
• Clear polycarbonate door lets staff check product without opening it. The door stays open past 90° for loading and closes by itself when opened 90° or less
• Door can be reversed in the field to suit the layout
• Control drawer slides out for cleaning and service
• Four pre-installed casters, two locking and two swivel
• Plugs into 120 V with a 10 ft power cord, no hardwiring needed
• Heats from 72°F to 160°F in about 15 minutes

Atosa ATWC-24 specifications

Brand	Atosa (CookRite line)
Model number	ATWC-24
Product type	Insulated economy warming and holding cabinet, full height, mobile
Doors	1, clear polycarbonate, field reversible, stays open past 90°
Pan capacity	24 pans, 18" x 26"
Exterior width	21-1/2"
Exterior depth	31-3/4"
Exterior height	69-3/4"
Temperature range	90°F to 205°F
Controls	Dial thermostat with LED temperature display
Electrical	120 V / 60 Hz / 1-phase, 13.2 A
Power	1,580 W
Cord length	10 ft
Exterior material	Stainless steel
Interior material	Stainless steel, integrated pan slides
Insulation	Fully insulated with environmentally friendly foaming material
Casters	4 pre-installed, 2 locking and 2 swivel
Gross weight	220 lb
Certifications	cETLus, ETL Sanitation
Warranty	1 year parts and labor

Frequently asked questions

What electrical connection does the Atosa ATWC-24 need?

It needs a grounded 120 V, 60 Hz, single-phase outlet within reach of its 10 ft cord. The cabinet draws 13.2 A (1,580 W), so plan on a circuit that is not shared with other high-draw equipment.

What temperature does the ATWC-24 hold?

It adjusts from 90°F to 205°F. That covers normal hot holding, and food is commonly held at 135°F or above. This is a heated holding cabinet only. It does not refrigerate and does not proof.

How much does the ATWC-24 hold?

It holds twenty-four 18" x 26" pans on its built-in slides.

Will the ATWC-24 fit through a standard doorway?

Yes. At 21-1/2" wide and 31-3/4" deep, it fits through a 36" doorway either way, and at 69-3/4" tall it clears a standard 80" door opening.

What certifications does the ATWC-24 have?

It is cETLus listed and ETL Sanitation listed. cETLus means Intertek tested it to North American electrical safety standards for the U.S. and Canada. ETL Sanitation shows it meets the food equipment sanitation standard health inspectors look for in commercial kitchens.

What warranty comes with the ATWC-24?

It comes with Atosa's CookRite one-year parts and labor warranty, which starts on the date the unit ships from Atosa. Labor coverage is standard straight-time labor and reasonable travel time. You make claims directly to Atosa and need the model number, serial number and proof of purchase. The warranty does not cover alteration, neglect, abuse, misuse, accidents, damage in transit or during installation, fire, flood or acts of God. It does not cover lost food or other consequential losses. Only the original purchaser is covered, and the warranty cannot be transferred.

How fast does the ATWC-24 heat up?

It takes about 15 minutes to go from a 72°F room to 160°F inside the cabinet.

How does the ATWC-24 differ from the ATWC-12 and ATHC-18P?

The ATWC-12 is the half-height version. It holds 12 pans, stands 42-3/4" tall and has the same 21-1/2" by 31-3/4" footprint and 120 V, 13.2 A, 1,580 W electrical. The ATHC-18P holds 18 pans and runs at 2,000 W. It heats up to 220°F and adds a humidifying water tray, so it suits operators who need moisture control.

Does it ship free, and how is it delivered?

Yes, this model ships free. It ships on a pallet by freight truck. A lift gate fee applies to large items like this one if you don't have a loading dock and is calculated at checkout.
