Atosa Stainless Steel Undercounter Freezer, 2 Door 48" - Field - AUF48SD

The Atosa AUF48SD is a two-section reach-in undercounter freezer for restaurants, bars and commercial kitchens that need frozen storage on the line, under a counter. It measures 48-1/4" wide, 30" deep and 32-1/2" high and holds 11.8 cu. ft. behind two solid hinged doors that can be switched to open the other way on site. A digital controller holds -8°F to 0°F, using a rear-mounted, self-contained 1/3 HP R290 refrigeration system. It runs on 115V and plugs into a standard NEMA 5-15 outlet. East Bay Restaurant Supply ships this model with free shipping.

Key features

• Two-section undercounter freezer with 11.8 cu. ft. of storage
• Electronic digital temperature controller, -8°F to 0°F range
• Two solid hinged doors that can be reversed on site
• Self-closing doors with a stay-open feature for loading
• Magnetic door gaskets seal each door tightly
• Automatic condensate evaporation and electric defrost
• Stainless steel interior and exterior with a galvanized steel back
• Two adjustable epoxy-coated wire shelves, one per section
• Rear-mounted, self-contained refrigeration with R290 hydrocarbon refrigerant
• 2" casters come installed from the factory
• cETLus listed and ETL-Sanitation certified

Atosa AUF48SD specifications

Brand	Atosa
Model number	AUF48SD
Product type	Reach-in undercounter freezer
Sections / doors	2 sections, 2 solid hinged doors, field reversible
Capacity	11.8 cu. ft.
Exterior width	48-1/4"
Exterior depth	30"
Exterior height	32-1/2"
Temperature range	-8°F to 0°F
Temperature control	Electronic digital controller
Refrigeration	Self-contained, rear-mounted
Refrigerant	R290 hydrocarbon
Compressor	1/3 HP
Defrost	Electric defrost, automatic condensate evaporation
Electrical	115 V / 60 Hz / 1-phase, 2.6 A
Plug	NEMA 5-15P
Shelves	2 adjustable epoxy-coated wire shelves (1 per section)
Exterior material	Stainless steel, galvanized steel back
Interior material	Stainless steel
Door gaskets	Magnetic
Casters	2", pre-installed
Shipping weight	249 lb
Certifications	cETLus, ETL-Sanitation
Warranty	2 years parts and labor, plus 3 more years on the sealed compressor (5 years total)

Frequently asked questions

Is the Atosa AUF48SD a freezer or a refrigerator?

The AUF48SD is a freezer that holds -8°F to 0°F. The matching refrigerator in the same 48" cabinet is the Atosa AUR48SD, which holds 35°F to 38°F.

What outlet does the AUF48SD need?

It needs a standard 115V grounded NEMA 5-15R outlet. It draws 2.6 A on a 115V, 60 Hz, single-phase supply. Atosa says to use a dedicated, properly grounded outlet. The warranty does not cover damage from extension cords, low voltage or voltage drops.

Will it fit through a standard doorway?

Yes. The cabinet is 30" deep and 32-1/2" high, so it rolls upright through a 36" doorway and is far below an 80" door opening.

Will it fit under my counter?

The AUF48SD is 32-1/2" high, 48-1/4" wide and 30" deep, so check that your counter's clear height and opening width are larger than these numbers. A 48" opening is too narrow. The refrigeration system is mounted at the rear, so leave room for airflow behind the unit.

What certifications does it have?

The AUF48SD is cETLus listed and ETL-Sanitation certified. cETLus means it was tested to US and Canadian electrical safety standards. ETL-Sanitation means it meets North American food equipment sanitation standards, which health inspectors look for in commercial kitchens.

What warranty comes with the AUF48SD?

Atosa covers parts and labor for 2 years from the original installation date or 27 months from shipment, whichever comes first. The sealed compressor is covered for 3 more years, up to 5 years total. The extra compressor coverage applies only to the sealed compressor parts. It does not cover the cabinet, temperature control, refrigerant, fan assembly or other electrical parts. The warranty does not cover alteration, neglect, misuse, accidents, damage in transit or during installation, fire, flood, or problems caused by bad electrical supply. It also cannot be transferred, and routine maintenance must be done to keep it valid.

How does the AUF48SD compare with other Atosa undercounter freezers?

The AUF48SD sits between the AUF36SD and the AUF60SD in Atosa's two-door line. The AUF36SD is 36-3/8" wide and holds 8.6 cu. ft. The AUF60SD is 60-1/4" wide and holds 15 cu. ft. All three are 30" deep, 32-1/2" high, hold -8°F to 0°F and use a 1/3 HP compressor on 115V. The AUF48SD replaces the older Atosa MGF8406GR.

Does it ship free, and how is it delivered?

Yes, this model ships free. It ships on a pallet by freight truck. A lift gate fee applies to large items like this one if you don't have a loading dock and is calculated at checkout.
