Atosa Stainless Steel Countertop Electric Fryer 16 lb - 208/240V ACEF-16

The Atosa ACEF-16 is a single-tank countertop electric fryer for cafes, bars, food trucks, concession stands and cook lines that need a dedicated fryer without giving up floor space to a floor model. It holds 16 lb of oil, comes with one nickel-plated basket, and measures 11-1/4" wide by 18-1/2" deep by 17-3/16" high. The thermostat adjusts from 70°F to 375°F, and a high-limit control with manual reset protects against overheating. The fryer runs on 208 to 240 V, 60 Hz, single-phase power, rated 2.9 kW to 3.8 kW and 14 to 15.1 A, with an attached cord and NEMA 6-20P plug. East Bay Restaurant Supply ships this model with free shipping.

Key features

• 16 lb oil capacity in a single stainless steel tank
• Thermostat adjusts from 70°F to 375°F (21.1°C to 190.5°C)
• High-limit temperature control with manual reset
• One nickel-plated fry basket with a coated, cool-to-touch insulated handle and wire mesh crumb screen
• Built-in basket hooks for draining product over the tank
• Control box and swing-up heating element lift out easily for cleaning
• All stainless steel construction
• Attached power cord with NEMA 6-20P plug, so no hardwiring is needed
• Compact 11-1/4" wide footprint for tight countertops and equipment stands
• cETLus listed for electrical safety and ETL Sanitation listed to NSF/ANSI Standard 4

Atosa ACEF-16 specifications

Brand	Atosa (CookRite line)
Model number	ACEF-16
Product type	Countertop electric fryer
Oil tanks	1
Oil capacity	16 lb
Heating elements	1
Baskets included	1, nickel-plated, insulated handle
Basket dimensions	8-7/16" x 7-7/8" x 5-7/8"
Exterior width	11-1/4"
Exterior depth	18-1/2"
Exterior height	17-3/16"
Temperature range	70°F to 375°F (21.1°C to 190.5°C)
Controls	Thermostatic, with high-limit manual reset
Electrical	208 to 240 V, 60 Hz, single-phase
Power	2.9 kW to 3.8 kW
Rated current	14 to 15.1 A
Plug	NEMA 6-20P, attached cord
Construction	All stainless steel, stainless steel tank
Net weight	18.4 lb
Shipping weight	21.5 lb
Certifications	cETLus, ETL Sanitation (NSF/ANSI Standard 4)
Warranty	1 year parts and labor

Frequently asked questions

What outlet does the Atosa ACEF-16 need?

It needs a NEMA 6-20R receptacle on a 208 to 240 V, 60 Hz, single-phase circuit, which matches its attached NEMA 6-20P plug. It draws 14 to 15.1 A depending on supply voltage, and it will not run on a standard 120 V outlet.

Is there a 120 V version?

Yes. The Atosa ACEF-10 runs on 120 V with a NEMA 5-20P plug, rated 1.7 kW. It holds 10 lb of oil and comes with two baskets.

What temperature range does it hold?

The thermostat adjusts from 70°F to 375°F (21.1°C to 190.5°C). A high-limit control with manual reset cuts power if the oil overheats.

How much oil does it hold and what basket comes with it?

The single tank holds 16 lb of oil. One nickel-plated basket, about 8-7/16" x 7-7/8" x 5-7/8", is included, with a coated cool-to-touch handle and a wire mesh crumb screen.

How does the ACEF-16 compare with the ACEF-10 and ACEF-32?

The ACEF-10 has the same 11-1/4" width but is shorter at 15-3/8" high. It holds 10 lb of oil, includes two baskets and runs on 120 V. The ACEF-32 is 21-11/16" wide with two 16 lb tanks (32 lb total), two baskets, and two separate cords with NEMA 6-20P plugs, so it needs two 208 to 240 V receptacles.

What certifications does it have?

It is cETLus listed, so it meets US and Canadian electrical safety standards. It is also ETL Sanitation listed to NSF/ANSI Standard 4, the sanitation standard for commercial cooking equipment that health inspectors look for.

How do you clean it?

The control box and swing-up heating element lift out easily, so you can reach the stainless steel tank to drain and clean it. Before first use, Atosa says to wash the heater and pan with mild detergent, rinse them, and dry them thoroughly.

What warranty comes with it?

Atosa covers the ACEF-16 for one year of parts and labor from the date it ships from Atosa. Labor covers standard straight-time charges and reasonable travel time. The warranty does not cover damage from alteration, neglect, abuse, misuse, accident, transit or installation, fire, flood or acts of God. Claims go directly to Atosa and must include the model number, serial number and proof of purchase.

Does it ship free, and how is it delivered?

Yes, this model ships free. It ships on a pallet by freight truck. A lift gate fee applies to large items like this one if you don't have a loading dock and is calculated at checkout.
