T&S Brass Wall Mount Workboard Faucet Quarter-Turn 4" Centers, 1.0 GPM - B-2459

The T&S Brass B-2459 is a commercial wall mount workboard faucet built for bar sinks, prep areas, and workboard applications where a low-profile, wall-mounted mixing faucet is required. Manufactured in the USA and backed by a 1-year limited warranty, it gives operators a dependable, code-compliant fixture with straightforward serviceability.

• Commercial wall mount mixing faucet designed for workboard and bar sink applications, with 4" centers and a chrome plated brass body.

• Body is chrome plated brass, with a chrome plated escutcheon included; the gooseneck is capable of both swivel and rigid operation via an included lock washer for rigid conversion.

• Overall faucet width is 12", height is 8 7/8", and spout length is 3 1/16"; spout reach is 2-7/8" with 360-degree swivel.

• Connects via 1/2" NPT male inlets; operating pressure range is 20 to 125 psi, with a temperature range of 40°F to 140°F.

• Quarter-turn Eterna compression cartridges with spring checks prevent cross flow of water; 4" wrist action handles include color coded indexes for hot and cold identification.

• Includes the 014200-45 lock washer for rigid gooseneck conversion when a fixed spout position is needed.

• Certified to ASME A112.18.1/CSA B125.1, NSF 61-Section 9, and NSF 372.

• Meets ADA ANSI/ICC A117.1 requirements.

Dimensions: Width: 12" | Height: 8-7/8" | Spout Length: 3-1/16" | Spout Reach: 2-7/8" | Centers: 4"
